BOOSTER PUMPS & DELIVERY PUMPS

SpectraPure® Booster Pump Kits are ideal for use on water sources with pressures below 40 psi (2.8 bar) such as private wells, gravity feed water systems and high rise apartments.

Booster Pump Kits are available for manual use, automatic filling of reservoirs or sumps, and for use on RO Systems using pressurized holding tanks. Our pump kits include transformers for use on 115 volts AC/60 Hz, or 230 volts AC/50 Hz. The transformer for the 230 volts AC/50 Hz supply has a two pin European plug. Use low flow booster pump kits for systems up to 40 gpd, and high flow booster pump kits for systems up to 100 gpd.

A pressure gauge is necessary to monitor the booster pump pressure. If your systems does not have a pressure gauge, please see the SpectraPure® Pressure Gauge Kit.



  • Increases line pressure to any of SpectraPure® Line Pressure fed RO or DI Systems
  • Add-on to existing RO, RO/DI Drinking Water Systems (DWS™) or Permeate Pump Drinking Water Systems (DWS-PP™)
  • Boost incoming pressure to 80 psi for enhanced production and increased purity
  • Can be operated in any position
  • Whisper quiet
  • Advanced diaphragm technology and improved bearings extend pump life and lower noise
  • Sealed pump design protects from moisture and prolongs motor life
  • Adjustable pressure output



Manual Operated Booster Pump Kits

The Manual Operated Booster Pump Kits can be used on RO or RO/DI Systems with existing Liquid Level Controllers (LLC) , and the addition of a patch cord (BP-PATCH).
MODEL Volts AC Max. System
GPD (LPD) 		Price Ship. Wt.
(lbs./kgs.)		 QTY
BPLF-MO-115
 115 25 (95) $169.99 8.5 / 3.9
BPLF-MO-230
 230 25 (95) $170 8.5 / 3.9
BPHF-MO-115
 115 100 (378) $199.99 11.5 / 5.2
BPHF-MO-230
 230 100 (378) $204.99 11.5 / 5.2
















Booster Pump Kit with Liquid Level Controller

This Kit provides a Liquid Level Controller for a single reservoir. The Booster Pump will automatically shut down when the water level, in the reservoir, becomes full. (Kit comes with a 2 ft Patch Cord to connect the Booster Pump to the Liquid Level Control Box.)

MODEL Volts AC Max. System
GPD (LPD) 		Price Ship. Wt.
(lbs./kgs.)		 QTY
BPLF-LLC-115 115 25 (95) $249.99 9 / 4.1
BPLF-LLC-230 230 25 (95) $248 9 / 4.1
BPHF-LLC-115
 115 100 (378) $279.99 12 / 5.5
BPHF-LLC-230
 230 100 (378) $276 12 / 5.5


















Booster Pump Kit with Electronic Solenoid and Pressure Switch control

This Kit provides an Electronic Solenoid and Pressure Switch to control filling of a pressurized storage tank. (Any RO or RO/DI set-up that currently has an Automatic Shut-Off Valve (ASO), no matter what is used down-stream*, will have the ASO removed and replaced with the Electronic Solenoid.)

* Liquid Level Controllers (LLC), Pressurized Storage Tanks, and Floats











MODEL Volts AC Max. System
GPD 		Price Ship. Wt.
(lbs./kgs.)		 QTY
BPLF-PS-093-115
 115

Low Flow Booster Pump Assy, 115VAC, Pressure Switch
(For 25-50 GPD Systems)

$199.99 8.5 / 3.9
BPLF-PS-093-230
 230

Low Flow Booster Pump Assy, 230VAC, Pressure Switch
(For 25-50 GPD Systems w/ European Transformer)

 $199.99 8.5 / 3.9
BPHF-PS-093-115
 115

High Flow Booster Pump Assy, 115VAC, Pressure Switch w/ .093 Orfice Solenoid Valve (For 60-100 GPD Systems)

$229.99 11.5 / 5.2
BPHF-PS-093-230
 230

High Flow Booster Pump Assy, 230VAC, Pressure Switch w/ .093 Orfice Solenoid Valve (For 60-100 GPD Systems w/ European Transformer)

 $229.99 11.5 / 5.2
BPHF-PS-250/4-115
 115

High Flow Booster Pump Assy, 115VAC, Pres Switch w/.250 Orfice Sol Valve, 1/4Tubing (For 100-200 GPD Systems)

 $229.99 11.5 / 5.2
BPHF-PS-250/4-230
 230

High Flow Booster Pump Assy, 230VAC, Pres Switch w/.250 Orfice Sol Valve, 1/4Tubing (For 100-200 GPD Systems w/ European Transformer)

 $229.99 11.5 / 5.2
BPHF-PS-250/6-115
 115

High Flow Booster Pump Assy, 115VAC, Pres Switch w/.250 Orfice Sol Valve, 3/8Tubing (For >200 GPD Systems)

 $229.99 11.5 / 5.2
BPHF-PS-250/6-230
 230

High Flow Booster Pump Assy, 230VAC, Pres Switch w/.250 Orfice Sol Valve, 3/8Tubing (For >200 GPD Systems w/ European Transformer)

 $229.99 11.5 / 5.2
























Solenoid Valve Controllers
(with High & Low Floats)

  • Dual Level Switches (Senses High and Low levels)
  • Choose from Electric Float Switches or Pressure Switches. (Pressure Switches are used with a Pressurized Storage Tank)
  • Advanced technology for Liquid Level Control
  • Will also control booster pump using its power supply


MODEL DESCRIPTION Price QTY
LLC-SVC-2FLT-12-10 LLC, Solenoid Valve Controller, Dual Float Assembly, 3/4in Sol Valve w/ 10ft Cable (USED BEST WITH THE PRODUCER SYSTEM) $164.99
LLC-SVC-2FLT-2-10 LLC, Solenoid Valve Controller, Dual Float Assembly, 1/8in Sol Valve w/ 10ft Cable $160
LLC-SVC-2FLT-4-10 LLC, Solenoid Valve Controller, Dual Float Assembly, 1/4in Sol Valve w/ 10ft Cable $164.99
LLC-SVC-2PS LLC, Solenoid Valve Controller, Dual Pressure Switch Assembly
(FOR USE WITH BLADDER TANKS) 		$121.99



Booster Pump Accessories

MODEL Description Price Ship. Wt.
(lbs./kgs.)		 QTY
BP-PATCH 2 FT Patch Cord Assembly $12.99 0.5 / 0.23







Delivery Pumps

SpectraPure® Delivery Pumps are used to transfer water from a storage tank to a remote location, such as an aquarium, hydroponics system, coffee-maker.

We have access to a large number of different pumps. We recommend calling our Engineering Department to help you select the exact pump for your application.



  • Automatically activated
  • Self priming and can run dry
  • 120 volts AC 50/60 Hz
  • Self pressure regulating; maintains constant output pressure regardless of inlet pressure

MODEL GPM Flow at 20 PSI Price Ship. Wt.
(lbs./kgs.)		 QTY
PUMP-DEL-5800-1 1.0 GPM with 3/8" push fittings included   6 / 2.8
PLEASE CALL
*PUMP-DEL-550-5.5 4.9 GPM with 1/2 " FPT (comes with built-in demand pressure switch) Fittings not included   6 / 2.8
PLEASE CALL

The use of a bladder tank is recommended to prevent excessive cycling of the delivery pump.

*This pump is controlled by a built-in pressure sensing demand switch. When a faucet or valve is opened downstream from the pump, the line pressure drops and the pump automatically starts. Conversely, when the valve closes, the line pressure will increase, turning off the pump automatically.
